Proximity Sensor MNH 2-BHS

		MNH 2-BHS
Measuring principle		contactless measuring by eddy current
Measuring range		1 ... 3 mm typical from air gap; 4 mV/μm
Total measuring range		~ 0,3 ... 4 mm (Continuous signal range)
Air gap		typ. 0,5 ... 0,6 mm
Operating temperature		-40 °C up to +200 °C
Drift		< 5 % v. MB.
Linearity		±5 % v. MB.
Measurement objects		metallic; eddy current producing
Dynamic range		0 ... 5 kHz (-3 dB)
Operation		with suitable electronics (Freq. approx. 1 MHz)
Connection		4m FEP coaxial cable, with Lemo series "00" coax plug
Protection (DIN 40050)		IP 66
Series dispersion		< 5 %
